4x4 Matrix 16 Keypad Keyboard Module (Soldered from bottom)

The 4x4 Matrix 16 Keypad Keyboard Module gives you 16 push buttons arranged in 4 rows and 4 columns on one small board. Because the keys are wired as a matrix, all 16 can be read with just 8 microcontroller pins. This version has its header pins soldered on the bottom side of the board, so it is ready to plug into jumper wires or a socket.

4x4 Matrix 16 Keypad Keyboard Module Specifications

• Keys: 16 push buttons
• Layout: 4 rows × 4 columns matrix
• Interface: 8 pins (4 row lines and 4 column lines)
• Header: pins soldered on the bottom side
• Reading method: matrix scanning, for example with the Arduino Keypad library

4x4 Matrix 16 Keypad Keyboard Module Applications

• PIN code door locks and safes
• Calculator and number entry projects
• Menu navigation and control panels
• Quiz games and robot control
• Learning how matrix keyboards work

What's in the Box

• 1 × 4x4 matrix keypad module with 16 keys

Tip: Connect the 4 row and 4 column pins to 8 digital pins and let the Keypad library work out which key is pressed. If you are short of pins, an I2C expander such as the PCF8574 can read the whole keypad over just 2 wires.
