775-76030 DC MOTOR 12V 14000RPM

The 775-76030 DC MOTOR 12V 14000RPM is a high-speed 775-size brushed DC motor rated for 12 V and 14000 RPM. The 775 size is a popular choice for DIY power tools such as mini drills, table saws and grinders, as well as pumps, blowers and high-speed spindles. It runs from a 12 V DC supply or battery pack, and its speed can be adjusted with a PWM speed controller.

775-76030 DC MOTOR 12V 14000RPM Specifications

• Motor type: brushed DC motor, 775 size
• Model code: 775-76030
• Rated voltage: 12 V DC
• Speed: 14000 RPM at 12 V (as listed)
• Terminals: 2, reverse the polarity to reverse direction
• Speed control: by supply voltage or PWM

775-76030 DC MOTOR 12V 14000RPM Applications

• DIY mini drills, table saws and cutting tools
• Grinders, polishers and sanders
• Water pumps, blowers and fans
• Engineering and robotics projects that need high speed

What's in the Box

• 1 × 775-76030 DC motor, 12 V 14000 RPM

Tip: A 775 motor draws a large current when it starts or stalls, so use a high-current PWM controller or MOSFET driver, thick wires and a fuse. Always fit a guard over any blade or disc in a tool you build with it.
