Bidirectional Shift Register 74194

The Bidirectional Shift Register 74194 is a 4-bit universal shift register from the 74-series logic family. Two mode inputs let it hold its data, shift left, shift right or load all four bits in parallel on each clock edge, which makes it a classic chip for digital electronics labs, LED chasers and serial-to-parallel conversion.

Bidirectional Shift Register 74194 Specifications

• Function: 4-bit bidirectional universal shift register
• Modes (S1, S0): 00 hold, 01 shift right, 10 shift left, 11 parallel load
• Inputs: 4 parallel data inputs (A–D), plus shift-right and shift-left serial inputs
• Outputs: 4 parallel outputs (QA–QD)
• Clock: synchronous, positive-edge triggered
• Clear: asynchronous, active low
• Pins: 16
• Supply: 5 V for TTL versions; check the exact marking, such as 74LS194 or 74HC194

Bidirectional Shift Register 74194 Applications

• Digital logic labs and university courses
• LED chasers and running lights
• Serial-to-parallel and parallel-to-serial conversion
• Ring and Johnson counters

What's in the Box

• 1 × 74194 shift register IC

Tip: Tie the CLR pin (pin 1) high for normal operation; pulling it low resets all outputs. Add a 100 nF decoupling capacitor between VCC (pin 16) and GND (pin 8), placed close to the chip.
