Bluetooth Module HC-06 (4-pin)

The Bluetooth Module HC-06 adds wireless serial communication to Arduino and other microcontroller projects using classic Bluetooth (SPP). It connects to the TX and RX pins of your board and acts like a wireless serial cable to an Android phone, tablet or PC. The HC-06 works as a slave device only, which keeps it simple: pair it from your phone and start sending data.

Bluetooth Module HC-06 Specifications

• Bluetooth: version 2.0 + EDR, Serial Port Profile (SPP)
• Role: slave only
• Supply voltage: 3.6 V to 6 V on the VCC pin
• Logic level: 3.3 V on TXD and RXD
• Default settings: name HC-06, PIN 1234, 9600 baud
• AT commands: accepted while the module is not paired
• Range: about 10 m in open space
• Pins: VCC, GND, TXD, RXD

Bluetooth Module HC-06 Applications

• Controlling robot cars and RC models from an Android phone app
• Sending sensor readings wirelessly to a phone or PC
• Home automation and remote switching with relays
• Wireless serial debugging and data logging
• School projects with phone apps made in MIT App Inventor

What's in the Box

• 1 × HC-06 Bluetooth module, 4 pins

Tip: Connect the module TXD to the Arduino RX and RXD to TX. The RXD pin uses 3.3 V logic, so use a voltage divider such as 1 kΩ and 2 kΩ from a 5 V TX pin. The HC-06 uses classic Bluetooth, so it pairs with Android phones and PCs but not with iPhones.
