Bringsmart DC Motor 12V 330RPM

The Bringsmart DC Motor 12V 330RPM is a 12 V DC gear motor from Bringsmart with an output speed of 330 RPM. Its reduction gearbox gives a slower, stronger output than a plain DC motor, so it can turn wheels, pulleys and mechanisms without extra gearing. Running from 12 V makes it easy to power from common adapters, lead-acid batteries and 3S lithium packs.

Bringsmart DC Motor 12V 330RPM Specifications

• Brand: Bringsmart
• Type: DC gear motor
• Rated voltage: 12 V DC
• Output speed: 330 RPM
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a suitable motor driver

Bringsmart DC Motor 12V 330RPM Applications

• Drive wheels for robots, rovers and robot cars
• Conveyors, turntables and rotating displays
• Automated doors, valves and small lifting mechanisms
• DIY machines such as mixers, winders and pumps
• Engineering and robotics education projects

What's in the Box

• 1 × Bringsmart DC motor, 12 V, 330 RPM

Tip: Control it with an H-bridge motor driver rated for 12 V and for the motor's stall current, not directly from an Arduino or ESP32 pin. Lower voltages reduce the speed roughly in proportion; do not exceed 12 V.
