Conductive Pen CW2000

The Conductive Pen CW2000 draws electrically conductive traces with silver-filled ink. You can use it like a marker to repair broken or scratched tracks on circuit boards, restore worn contacts on membrane keypads and remote controls, or add small jumpers between pads, all without soldering. Because no heat is needed, it is safe to use near plastic parts and heat-sensitive components, and it is also handy for drawing simple circuits on paper in STEM classes.

Conductive Pen CW2000 Specifications

• Model: CW2000
• Ink: silver-filled conductive ink
• Curing: air dries at room temperature
• Use: draws conductive lines on circuit boards and most clean surfaces
• Format: marker-style pen

Conductive Pen CW2000 Applications

• Repairing damaged PCB traces and pads
• Fixing worn contacts on remote controls and membrane keypads
• Making small jumpers and connections on prototypes
• Drawing paper circuits with LEDs and coin cells in STEM classes

What's in the Box

• 1 × CW2000 conductive pen

Tip: Clean the surface with isopropyl alcohol first, shake the pen well so the silver is mixed, and draw a smooth line slightly wider than the original trace. Let it dry fully before powering the circuit and check the repair with a multimeter. For traces that carry high current, solder a wire instead.
