DC Motor 16GA-130 12V 8rpm

The DC Motor 16GA-130 12V 8rpm is a very slow 12 V DC gear motor with a miniature 16GA series gearbox. At about 8 rpm it takes roughly 7.5 seconds per revolution, and the large gear reduction gives strong torque for such a small motor. It is made for slow, steady movement in compact automation projects.

DC Motor 16GA-130 12V 8rpm Specifications

• Model: 16GA-130 gear motor
• Type: DC motor with reduction gearbox
• Rated voltage: 12 V DC
• Output speed: about 8 rpm at 12 V
• Gearbox: miniature 16 mm diameter class (16GA series)
• Direction: reversible by swapping the supply polarity
• Speed control: PWM through a motor driver

DC Motor 16GA-130 12V 8rpm Applications

• Slow rotating displays and product turntables
• Automatic feeders and dispensers
• Lock, valve and damper actuators
• Timed mechanisms, models and STEM projects

What's in the Box

• 1 × DC Motor 16GA-130 12V 8rpm gear motor

Tip: A motor this slow is easy to position by timing: switch it on through a driver or relay for a set time, and add a limit switch for a reliable end point. Check that your 12 V supply can deliver the motor's start-up current.
