PM25L-024-BRW6

The PM25L-024-BRW6 is a 2-phase PM (permanent-magnet, can-stack) stepper motor with a body diameter of about 25 mm. Its 024 code stands for 24 full steps per revolution, a step angle of 15°. It moves to exact positions by counting pulses, with no encoder needed, which makes it a simple and low-cost option for actuators, dispensers and small automation built around an Arduino or ESP32.

PM25L-024-BRW6 Specifications

• Motor type: 2-phase permanent-magnet (PM) stepper motor
• Body diameter: about 25 mm (from the PM25 code)
• Full steps per revolution: 24
• Step angle: 15° full step, 7.5° in half-step mode
• Variant code: BRW6

PM25L-024-BRW6 Applications

• Small actuators, latches and flaps
• Automatic pet feeders and dispensers
• Rotating signs and display mechanisms
• Electronics and robotics education

What's in the Box

• 1 × PM25L-024-BRW6 stepper motor

Tip: Identify the coils with a multimeter: wires that show resistance between them belong to the same coil. Connect each coil to one output pair of an H-bridge driver such as the DRV8833, and swap one pair if the motor turns the wrong way.
