SPST Slide Switch 5pcs

The SPST Slide Switch pack contains five single-pole single-throw slide switches for simple on/off control. Slide the actuator one way to close the circuit and the other way to open it, which makes them a good fit as power switches for battery-powered gadgets, robots and Arduino projects. They are also handy for setting a mode or configuration input on a microcontroller.

SPST Slide Switch Specifications

• Switch type: slide switch
• Configuration: SPST (single pole, single throw), on/off
• Function: connects or breaks one circuit
• Pack size: 5 pieces

SPST Slide Switch Applications

• On/off switches for battery packs, toys and small gadgets
• Main power switch for robot cars and portable projects
• Mode or setting inputs read by an Arduino digital pin
• Enabling or disabling part of a circuit during testing
• Electronics classes and STEM kits

What's in the Box

• 5 × SPST slide switches

Tip: To read the switch with an Arduino, wire it between a digital pin and GND and use pinMode(pin, INPUT_PULLUP); the pin then reads LOW when the switch is on. Small slide switches are meant for low currents, so for motors or other heavy loads let the switch control a relay or MOSFET instead.
