Ceramic Capacitor (100) 10pF 100V (5 pcs)

The Ceramic Capacitor (100) 10pF pack contains five non-polarised ceramic capacitors with a capacitance of 10 pF and a voltage rating of 100 V. The code 100 means 10 followed by no zeros, in picofarads, so these are 10 pF capacitors, not 100 pF. Small values like this are used in crystal oscillators, RF stages and high-frequency filters.

Ceramic Capacitor (100) 10pF Specifications

• Capacitance: 10 pF (0.01 nF)
• Marking code: 100
• Voltage rating: 100 V
• Type: ceramic, non-polarised
• Mounting: through-hole, 2 leads
• Pack size: 5 pieces

Ceramic Capacitor (100) 10pF Applications

• Load capacitors for crystal oscillators whose datasheet calls for a low load capacitance
• RF matching, tuning and antenna circuits
• Small feedback capacitors for op-amp stability
• High-frequency coupling and filtering
• Electronics education and radio projects

What's in the Box

• 5 × 10 pF (100) 100 V ceramic capacitors

Tip: For a crystal, the two load capacitors in series plus the stray capacitance of the board should match the crystal's specified load capacitance. Many ATmega328P breadboard builds use two 22 pF capacitors with a 16 MHz crystal, so check the crystal datasheet before changing values.
