Ceramic Capacitor (101) 100pF 100V (5 pcs)

The Ceramic Capacitor (101) 100pF pack contains five non-polarised ceramic capacitors with a capacitance of 100 pF and a voltage rating of 100 V. The code 101 means 10 followed by one zero, in picofarads, so a part marked 101 is 100 pF (a part marked 100 is only 10 pF). It is a common value for high-frequency filtering, oscillators and signal conditioning.

Ceramic Capacitor (101) 100pF Specifications

• Capacitance: 100 pF (0.1 nF)
• Marking code: 101
• Voltage rating: 100 V
• Type: ceramic, non-polarised
• Mounting: through-hole, 2 leads
• Pack size: 5 pieces

Ceramic Capacitor (101) 100pF Applications

• Filtering RF and high-frequency noise on audio and sensor inputs
• Oscillator, timing and clock circuits
• RC low-pass filters on signal lines
• Feedback compensation in op-amp circuits
• Electronics education and prototyping

What's in the Box

• 5 × 100 pF (101) 100 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. With a 10 kΩ resistor, 100 pF forms a low-pass filter with a cut-off of about 159 kHz, which passes audio but blocks radio-frequency interference.
