Ceramic Capacitor (104) 100nF 100V (5 pcs)

The Ceramic Capacitor (104) 100nF pack contains five non-polarised ceramic capacitors with a capacitance of 100 nF (0.1 µF) and a voltage rating of 100 V. The code 104 means 10 × 10⁴ pF. 100 nF is the standard decoupling value placed next to ICs and microcontrollers, and the 100 V rating gives extra margin on 12 V, 24 V and 48 V lines and across noisy DC motors.

Ceramic Capacitor (104) 100nF Specifications

• Capacitance: 100 nF = 0.1 µF = 100,000 pF
• Marking code: 104
• Voltage rating: 100 V DC
• Type: ceramic, non-polarised
• Mounting: through-hole
• Pack size: 5 pieces

Ceramic Capacitor (104) 100nF Applications

• Decoupling the power pins of ICs, Arduino and ESP32 boards
• Suppressing electrical noise across DC motor terminals
• Filtering on 12 V, 24 V and 48 V supply lines
• Debouncing push buttons together with a resistor
• Electronics education and prototyping

What's in the Box

• 5 × 100 nF (104) 100 V ceramic capacitors

Tip: For decoupling, place the capacitor as close as possible to the IC's VCC and GND pins and keep the leads short. Ceramic capacitors have no polarity, so they can be fitted either way round. Keep the voltage below 100 V.
