Ceramic Capacitor (105) 1uF (1000nF) 100V (5 pcs)

The Ceramic Capacitor (105) 1uF pack contains 5 non-polarised ceramic capacitors of 1 µF (1000 nF) each, rated 100 V. The code 105 means 10 followed by five zeros in picofarads, or 1,000,000 pF. A 1 µF ceramic capacitor is a popular choice for decoupling and for the input and output of voltage regulators.

Ceramic Capacitor (105) 1uF Specifications

• Capacitance: 1 µF (1000 nF, 1,000,000 pF)
• Marking code: 105
• Rated voltage: 100 V
• Type: ceramic capacitor, non-polarised
• Pack size: 5 pieces

Ceramic Capacitor (105) 1uF Applications

• Decoupling and bypass on microcontroller and sensor supply pins
• Input and output capacitors for voltage regulators
• Filtering ripple on DC supplies
• Coupling and timing in analog circuits
• Replacing small electrolytic capacitors where a non-polarised part is preferred

What's in the Box

• 5 × 1 µF 100 V ceramic capacitors

Tip: Place decoupling capacitors as close as possible to the IC power pins. High-value ceramic capacitors can lose some capacitance with DC voltage applied, so the 100 V rating gives extra margin in 5 V to 24 V circuits.
