10mm White Leg Led (1Pcs)

The 10mm White Leg Led is a large 10 mm round through-hole LED that gives a bright white light. Its bigger lens is easier to see than standard 3 mm or 5 mm LEDs, so it works well for indicator lamps, small lights, models and displays. The two legs plug straight into a breadboard or solder to a board, and it can be driven from an Arduino or ESP32 pin with a series resistor.

10mm White Leg Led Specifications

• LED size: 10 mm round
• Colour: white
• Mounting: through-hole, 2 legs
• Typical forward voltage: about 3.0–3.4 V
• Typical current: about 20 mA
• Pack size: 1 piece

10mm White Leg Led Applications

• Bright power and status indicators on panels
• Small lamps, night lights and torches
• Model houses, signs and dioramas
• Arduino and ESP32 beginner projects

What's in the Box

• 1 × 10 mm white LED

Tip: Always use a series resistor, about 100 Ω from a 5 V supply, to protect the LED. The longer leg is the anode (+) and goes to the positive side. From a 3.3 V pin the LED may look dim, because its forward voltage is close to 3.3 V.
