Ceramic Capacitor (153) 15nF 50V (5 pcs)

The Ceramic Capacitor (153) 15nF 50V is a non-polarised through-hole ceramic capacitor with a capacitance of 15 nF (0.015 µF) and a 50 V rating, sold in a pack of 5. The code 153 printed on the body means 15 followed by three zeros in picofarads, which is 15,000 pF. It is a handy value for RC filters, 555 timer circuits and suppressing noise on signal lines.

Ceramic Capacitor (153) 15nF 50V Specifications

• Capacitance: 15 nF (0.015 µF, 15,000 pF)
• Marking code: 153
• Voltage rating: 50 V
• Type: ceramic, non-polarised
• Mounting: through-hole, 2 leads
• Pack size: 5 pieces

Ceramic Capacitor (153) 15nF 50V Applications

• Low-pass and high-pass RC filters
• Timing capacitor in NE555 and RC oscillator circuits
• Filtering high-frequency noise on sensor and signal lines
• Tone and filter networks in audio circuits
• Electronics education and prototyping

What's in the Box

• 5 × 15 nF (153) 50 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. For an RC low-pass filter the cut-off frequency is f = 1 / (2πRC): with this 15 nF capacitor and a 10 kΩ resistor it is about 1.06 kHz.
