Ceramic Capacitor (154) 150nF 50V (5 pcs)

The Ceramic Capacitor (154) 150nF 50V is a non-polarised through-hole ceramic capacitor with a capacitance of 150 nF (0.15 µF) and a 50 V rating, sold in a pack of 5. The code 154 printed on the body means 15 followed by four zeros in picofarads, which is 150,000 pF. It is used for decoupling ICs, filtering supply and signal noise, and in coupling and timing circuits.

Ceramic Capacitor (154) 150nF 50V Specifications

• Capacitance: 150 nF (0.15 µF, 150,000 pF)
• Marking code: 154
• Voltage rating: 50 V
• Type: ceramic, non-polarised
• Mounting: through-hole, 2 leads
• Pack size: 5 pieces

Ceramic Capacitor (154) 150nF 50V Applications

• Decoupling capacitors next to microcontrollers and logic ICs
• Filtering noise on power and sensor lines
• Coupling audio and AC signals between stages
• Debouncing push buttons together with a resistor
• RC filter and timing circuits

What's in the Box

• 5 × 150 nF (154) 50 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. For a simple button debounce, the RC time constant is R × C: a 10 kΩ resistor with this 150 nF capacitor gives 1.5 ms, enough to smooth out most switch bounce.
