170pts Mini Breadboard SYB-170 (Blue)

The 170pts Mini Breadboard SYB-170 is a small blue solderless breadboard with 170 tie points. It is just big enough for a sensor, a few LEDs or a small IC, so it suits compact projects, robot cars and project boxes where a full-size board will not fit. Components and jumper wires push in and pull out without soldering, so the board can be reused many times.

170pts Mini Breadboard SYB-170 Specifications

• Model: SYB-170
• Tie points: 170
• Layout: 17 columns, each with two groups of 5 connected holes on either side of a centre channel
• Power rails: none, bring in power and ground with jumper wires
• Hole pitch: 2.54 mm (0.1 in), fits pin headers and DIP ICs
• Colour: blue

170pts Mini Breadboard SYB-170 Applications

• Small sensor and LED circuits with Arduino or ESP32
• Mounting on robot car chassis and inside project boxes
• Testing a single DIP IC, such as a 555 timer, before soldering
• Classroom kits where each student needs a small board

What's in the Box

• 1 × SYB-170 mini breadboard, blue

Tip: Because this board has no power rails, choose one 5-hole group for 5 V and another for GND, and use red and black jumper wires for them so the supply lines are easy to tell apart.
