1N4007 DIP 0.5W(5pcs)

The 1N4007 is a general-purpose silicon rectifier diode rated for 1 A average forward current and 1000 V reverse voltage, sold here in a pack of 5. It is the highest-voltage member of the 1N400x family, so it can replace any 1N4001 to 1N4006 and is a reliable choice for rectifying AC, protecting circuits from reverse polarity and absorbing voltage spikes from relays and motors.

1N4007 Diode Specifications

• Type: silicon rectifier diode
• Maximum repetitive reverse voltage: 1000 V
• Average forward current: 1 A
• Peak surge current: 30 A (8.3 ms half sine wave)
• Forward voltage: 1.1 V max at 1 A
• Package: DO-41 axial, through-hole
• Pack size: 5 pieces

1N4007 Diode Applications

• Bridge and half-wave rectifiers in transformer power supplies
• Reverse-polarity protection on battery and DC inputs
• Flyback (freewheeling) diodes across relay coils and DC motors
• Blocking diodes in battery charging and solar circuits
• Electronics repair and prototyping

What's in the Box

• 5 × 1N4007 rectifier diodes

Tip: The band on the body marks the cathode (−). As a relay or motor flyback diode, connect the band to the positive supply side so it only conducts when the coil switches off. The 1N4007 is made for 50/60 Hz rectification; for fast switching circuits use a fast-recovery or Schottky diode.
