Ceramic Capacitor (221) 220pF 50V (5 pcs)

The Ceramic Capacitor (221) 220pF is a small non-polarised ceramic capacitor with a capacitance of 220 pF and a 50 V rating, sold in a pack of 5. Small picofarad values like this are used in high-frequency circuits: filtering noise on signal lines, setting oscillator frequencies, and stabilising amplifiers and RF stages.

Ceramic Capacitor (221) 220pF Specifications

• Capacitance: 220 pF (0.22 nF)
• Marking code: 221 (22 followed by 1 zero, in pF)
• Voltage rating: 50 V
• Type: ceramic, non-polarised, through-hole
• Pack size: 5 pieces

Ceramic Capacitor (221) 220pF Applications

• Filtering high-frequency noise on signal and sensor lines
• Oscillator and timing circuits
• Radio, RF and antenna tuning circuits
• Frequency compensation in op-amp and transistor amplifiers
• RC low-pass filters on PWM and audio signals

What's in the Box

• 5 × 220 pF (221) 50 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. Keep the voltage across them below 50 V, and keep the leads short in high-frequency circuits, because long leads add inductance and pick up noise.
