Ceramic Capacitor (222) 2200pF 2.2nf 100V (5 pcs)

The Ceramic Capacitor (222) 2200pF is a non-polarised ceramic capacitor with a capacitance of 2200 pF (2.2 nF) and a 100 V rating, sold in a pack of 5. It is marked with the code 222, which means 22 followed by two zeros in picofarads. This value is often used for noise filtering, RC timing, small snubbers and signal coupling in analog and digital circuits.

Ceramic Capacitor (222) 2200pF Specifications

• Capacitance: 2200 pF = 2.2 nF = 0.0022 µF
• Marking code: 222
• Voltage rating: 100 V
• Type: ceramic, non-polarised
• Pack size: 5 pieces

Ceramic Capacitor (222) 2200pF Applications

• RC filters and noise suppression on signal lines
• Timing capacitors for 555 timers and oscillators
• Small snubber networks in low-voltage switching circuits
• Coupling and bypass in audio and RF circuits
• Electronics education and prototyping

What's in the Box

• 5 × 2200 pF (2.2 nF) 100 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. Keep the working voltage well below 100 V and never use them across mains lines, which need safety-rated X or Y capacitors. With a 10 kΩ resistor, 2.2 nF gives an RC low-pass cut-off of about 7.2 kHz.
