Ceramic Capacitor (222) 2200pF 2.2nF 50V (5 pcs)

The Ceramic Capacitor (222) 2200pF pack contains five non-polarised ceramic capacitors with a capacitance of 2200 pF (2.2 nF) and a voltage rating of 50 V. The code 222 printed on the body means 22 × 10² pF. This small value is used in RC filters, timing and oscillator circuits, and for filtering high-frequency noise in analog and digital projects.

Ceramic Capacitor (222) 2200pF Specifications

• Capacitance: 2200 pF = 2.2 nF = 0.0022 µF
• Marking code: 222
• Voltage rating: 50 V DC
• Type: ceramic, non-polarised
• Mounting: through-hole
• Pack size: 5 pieces

Ceramic Capacitor (222) 2200pF Applications

• RC low-pass and high-pass filters
• Timing capacitor for 555 and oscillator circuits (a 555 astable with two 10 kΩ resistors runs at about 22 kHz)
• Filtering high-frequency noise on signal lines and sensor inputs
• Coupling and bypass in audio and radio circuits
• Electronics education and prototyping

What's in the Box

• 5 × 2.2 nF (222) 50 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. To read the code, the first two digits are the value and the third is the number of zeros in picofarads, so 222 = 2200 pF. Keep the voltage below 50 V.
