Ceramic Capacitor (223) 22nF 100V (5 pcs)

The Ceramic Capacitor (223) 22nF 100V is a non-polarised ceramic capacitor with a capacitance of 22 nF (0.022 µF) and a 100 V voltage rating, sold in a pack of 5. It is a handy mid-range value for timing, signal coupling and filtering, and the 100 V rating leaves plenty of margin in 5 V, 12 V and 24 V circuits.

Ceramic Capacitor (223) 22nF 100V Specifications

• Capacitance: 22 nF (0.022 µF, 22,000 pF)
• Marking code: 223 (22 followed by 3 zeros, in pF)
• Voltage rating: 100 V
• Type: ceramic, non-polarised
• Pack size: 5 pieces

Ceramic Capacitor (223) 22nF 100V Applications

• Timing capacitor for 555 timers and RC oscillators
• Coupling audio and sensor signals between amplifier stages
• RC filters on the analog inputs of Arduino and ESP32 boards
• Extra high-frequency bypass next to larger decoupling capacitors
• Noise suppression in relay and motor circuits

What's in the Box

• 5 × 22 nF (223) 100 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. In a 555 astable circuit with R1 = R2 = 10 kΩ, this 22 nF capacitor gives roughly 2.2 kHz, using f ≈ 1.44 / ((R1 + 2 × R2) × C).
