Ceramic Capacitor (334) 330nF 50V (5 pcs)

The Ceramic Capacitor (334) 330nF 50V is a non-polarised ceramic capacitor with a capacitance of 330 nF (0.33 µF) and a 50 V rating, sold in a pack of 5. It is best known as the 0.33 µF input capacitor recommended for 78xx voltage regulators such as the 7805, and it is also used for decoupling, filtering and signal coupling.

Ceramic Capacitor (334) 330nF 50V Specifications

• Capacitance: 330 nF (0.33 µF, 330,000 pF)
• Marking code: 334 (33 followed by 4 zeros, in pF)
• Voltage rating: 50 V
• Type: ceramic, non-polarised
• Pack size: 5 pieces

Ceramic Capacitor (334) 330nF 50V Applications

• Input capacitor for 7805, 7809 and 7812 regulators, with 0.1 µF on the output
• Decoupling and noise filtering on IC power pins
• Low-pass and high-pass RC filters
• Coupling audio and sensor signals between stages
• Electronics education and prototyping

What's in the Box

• 5 × 330 nF (334) 50 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. Place it as close as possible to the regulator's input and ground pins, especially when the regulator is far from the main filter capacitor.
