Crystal Oscillator 4.915MHz

The Crystal Oscillator 4.915MHz is a 4.915 MHz quartz crystal that gives an oscillator circuit a stable, accurate reference frequency. Frequencies around 4.9152 MHz are popular for serial communication, because 4.9152 MHz divides exactly into standard baud rates such as 9600, 19200 and 38400. Use it with a microcontroller, a UART chip or a discrete oscillator circuit.

Crystal Oscillator 4.915MHz Specifications

• Frequency: 4.915 MHz
• Type: quartz crystal, two-terminal (passive), needs an oscillator circuit to run
• Load capacitors: one small ceramic capacitor from each pin to GND; the value depends on the crystal's load capacitance and the chip's datasheet
• Polarity: none, can be fitted either way round

Crystal Oscillator 4.915MHz Applications

• Baud-rate clocks for UARTs and serial interfaces
• Clock source for microcontrollers that support this frequency
• Crystal oscillator circuits and clock dividers, for example with a CD4060
• Replacing a faulty crystal when repairing modems, terminals and other equipment
• Frequency and timing experiments in electronics labs

What's in the Box

• 1 × 4.915 MHz crystal

Tip: Place the crystal and its load capacitors close to the chip's oscillator pins with short tracks. If your design needs an exact baud rate, check that the crystal is marked 4.9152 MHz.
