Ceramic Capacitor (470) 47pF 50V (5 pcs)

The Ceramic Capacitor (470) 47pF is a small non-polarised ceramic capacitor of 47 pF rated for 50 V, sold in a pack of 5. Its body is marked 470: the first two digits are 47 and the last digit 0 means no zeros are added, so the value is 47 pF. Small values like this are used in RF circuits, oscillators and as feedback capacitors that keep op-amps stable.

Ceramic Capacitor (470) 47pF Specifications

• Capacitance: 47 pF
• Marking code: 470
• Voltage rating: 50 V
• Type: ceramic, non-polarised
• Mounting: through-hole leads
• Pack size: 5 pieces

Ceramic Capacitor (470) 47pF Applications

• Small capacitors across op-amp feedback resistors to limit bandwidth and prevent oscillation
• RF tuning, coupling and matching
• Oscillator circuits
• High-frequency filters
• Radio and communication projects

What's in the Box

• 5 × 47 pF 50 V ceramic capacitors

Tip: Do not confuse the code 470 (47 pF) with 471 (470 pF) or 473 (47 nF). For RF work keep the leads short, because long leads add inductance and stray capacitance that change how the circuit behaves.
