Ceramic Capacitor (474) 470nF 400V

The Ceramic Capacitor (474) 470nF is a non-polarised ceramic capacitor with a capacitance of 470 nF (0.47 µF) and a voltage rating of 400 V. The code 474 printed on the body means 47 followed by four zeros in picofarads. Its high voltage rating suits it to snubber and filtering circuits in power electronics, as well as general coupling and bypass work where extra voltage headroom is needed.

Ceramic Capacitor (474) 470nF Specifications

• Capacitance: 470 nF (0.47 µF, 470,000 pF)
• Marking code: 474
• Rated voltage: 400 V
• Dielectric: ceramic
• Polarity: non-polarised, fits either way round

Ceramic Capacitor (474) 470nF Applications

• RC snubbers across relay contacts, switches and motor brushes
• Filtering on high-voltage DC rails in power supplies
• Coupling and bypass in circuits with higher voltages
• Repair of power supplies, chargers and appliances

What's in the Box

• 1 × 470 nF 400 V ceramic capacitor (474)

Tip: Choose a capacitor rated well above the highest voltage in your circuit. Unless the body carries an X or Y safety marking, do not connect a ceramic capacitor directly across the mains or from mains to earth; use a certified X2 or Y capacitor there.
