Ceramic Capacitor (474) 470nF 100V (5 pcs)

The Ceramic Capacitor (474) 470nF 100V is a non-polarised ceramic capacitor with a capacitance of 470 nF (0.47 µF) and a 100 V rating, sold in a pack of 5. It is a useful larger ceramic value for decoupling and noise filtering on supply lines, RC timing and coupling, and the 100 V rating leaves plenty of margin in 12 V, 24 V and 48 V circuits.

Ceramic Capacitor (474) 470nF 100V Specifications

• Capacitance: 470 nF (0.47 µF, 470,000 pF)
• Marking code: 474 (47 followed by 4 zeros, in pF)
• Voltage rating: 100 V
• Type: ceramic, non-polarised
• Pack size: 5 pieces

Ceramic Capacitor (474) 470nF 100V Applications

• Decoupling and noise filtering on power rails
• Input and output capacitors for voltage regulators
• RC timing and low-pass filter circuits
• Coupling signals between amplifier stages
• Suppressing brush noise across small DC motors

What's in the Box

• 5 × 470 nF (474) 100 V ceramic capacitors

Tip: Ceramic capacitors have no polarity, so they can be fitted either way round. To read the code, the first two digits are the value and the third is the number of zeros in picofarads: 474 means 470,000 pF, which is 470 nF.
