Ceramic Capacitor (681) 680pF 100V (5 pcs)

The Ceramic Capacitor (681) 680pF 100V is a small-value, non-polarised ceramic capacitor of 680 pF with a 100 V voltage rating, sold in a pack of 5. Values in the hundreds of picofarads are used where signals change quickly, such as in high-frequency filters, oscillators and op-amp feedback loops.

Ceramic Capacitor (681) 680pF 100V Specifications

• Capacitance: 680 pF (0.68 nF)
• Marking code: 681 (68 followed by 1 zero, in pF)
• Voltage rating: 100 V
• Type: ceramic, non-polarised
• Pack size: 5 pieces

Ceramic Capacitor (681) 680pF 100V Applications

• Feedback capacitor across an op-amp resistor to limit bandwidth and noise
• High-frequency noise filtering on signal lines
• RC timing in fast oscillator circuits
• RF and IF filter networks
• Prototyping, repairs and electronics classes

What's in the Box

• 5 × 680 pF (681) 100 V ceramic capacitors

Tip: Ceramic capacitors have no polarity. Placed across a 100 kΩ op-amp feedback resistor, 680 pF sets an upper cut-off of about 2.3 kHz (f = 1 / (2π × R × C)), which limits the bandwidth of a slow sensor amplifier and filters out higher-frequency noise.
