8 Channel Relay Module without light coupling 5V

The 8 Channel Relay Module is a 5 V relay board with eight independent relays, letting one microcontroller switch up to eight separate circuits. This version is without light coupling, meaning it has no optocouplers: each control input drives its relay through a transistor on the board. It is a compact way to control several lamps, fans, pumps or valves from an Arduino.

8 Channel Relay Module Specifications

• Channels: 8 independent relays
• Relay coil voltage: 5 V DC
• Isolation: no optocoupler (without light coupling)
• Control pins: VCC, GND and 8 signal inputs
• Load terminals: COM, NO (normally open) and NC (normally closed) for each channel
• Contact rating: printed on each relay body; check it before connecting a load

8 Channel Relay Module Applications

• Home automation with several lights and sockets
• Irrigation systems with multiple valve zones
• Greenhouse, aquarium and poultry farm control
• Control panels and test rigs
• Learning how relays work in electronics classes

What's in the Box

• 1 × 8-channel 5 V relay module

Tip: With several relays on at once the board draws more current than an Arduino's 5 V pin should supply, so power it from a separate 5 V supply of at least 1 A and connect its ground to the Arduino ground. Take great care with mains voltage: disconnect power before wiring and keep the high-voltage side covered.
