Ceramic Capacitor (334) 330nF 630V

The Ceramic Capacitor (334) 330nF 630V is a non-polarised capacitor with a capacitance of 330 nF (0.33 µF), marked with the code 334, and a voltage rating of 630 V. It is a larger value than most small ceramic capacitors, which makes it useful for decoupling, filtering and coupling in power supplies and other circuits that work at high DC voltages.

Ceramic Capacitor (334) 330nF 630V Specifications

• Capacitance: 330 nF (0.33 µF, 330,000 pF)
• Marking code: 334 (33 × 10⁴ pF)
• Rated voltage: 630 V
• Type: ceramic capacitor (as listed), non-polarised
• Mounting: through-hole, 2 leads

Ceramic Capacitor (334) 330nF 630V Applications

• Decoupling and bypass on high-voltage DC rails
• Filtering in switch-mode power supplies and LED drivers
• Signal coupling where a non-polarised capacitor is needed
• Repair and replacement in power supply and appliance boards

What's in the Box

• 1 × 330 nF (334) 630 V capacitor

Tip: Check the 334 marking on the body to confirm the value. Discharge any capacitor that has been charged to a high voltage before handling it, and do not connect it across the AC mains unless it carries an X or Y safety rating.

Orders placed before 14:00 are ready for pickup the same day. Delivery across Lebanon usually takes 1–3 working days.
