Electrolytic Capacitor (100V) 10uF (5pcs)

The Electrolytic Capacitor (100V) 10uF pack contains five polarised electrolytic capacitors with a capacitance of 10 µF and a high voltage rating of 100 V. These through-hole capacitors filter and decouple power rails and couple audio signals, and the 100 V rating gives a wide safety margin on 24 V and 48 V supplies and other higher-voltage stages.

Electrolytic Capacitor (100V) 10uF Specifications

• Capacitance: 10 µF
• Voltage rating: 100 V DC
• Type: electrolytic, polarised
• Mounting: through-hole
• Polarity marking: stripe on the negative side; the longer lead is positive
• Pack size: 5 pieces

Electrolytic Capacitor (100V) 10uF Applications

• Decoupling and filtering on 24 V and 48 V power rails
• Input capacitors for regulators and DC-DC converters running from higher voltages
• Audio coupling between amplifier stages
• 555 timer circuits (100 kΩ with 10 µF gives about 1.1 seconds in monostable mode)
• Repairs where a higher voltage rating is needed

What's in the Box

• 5 × 10 µF 100 V electrolytic capacitors

Tip: Electrolytic capacitors are polarised: connect the positive (longer) lead to the higher voltage and never reverse it, or the capacitor can overheat and fail. A higher voltage rating than needed is fine, so this capacitor can also replace 10 µF parts rated 16 V to 63 V if it fits the space.
