Electrolytic Capacitor(100V) 100uF (1 piece)

The Electrolytic Capacitor(100V) 100uF is a single aluminium electrolytic capacitor with a capacitance of 100 µF and a high maximum working voltage of 100 V. It suits filtering and decoupling in higher voltage DC circuits such as 48 V systems, motor controllers and audio amplifier power rails, where a 50 V capacitor would not leave enough safety margin.

Electrolytic Capacitor(100V) 100uF Specifications

• Capacitance: 100 µF
• Rated voltage: 100 V DC
• Type: aluminium electrolytic, polarised
• Mounting: through-hole, two leads
• Polarity marking: the stripe on the body marks the negative lead
• Pack size: 1 piece

Electrolytic Capacitor(100V) 100uF Applications

• Decoupling and bulk capacitance on 24 V, 36 V and 48 V supply rails
• Input capacitors for DC-DC converters with a high input voltage
• Motor controllers and drivers running from higher voltage batteries
• Power rails of audio amplifiers
• Repairing power supplies and control boards

What's in the Box

• 1 × 100 µF 100 V electrolytic capacitor

Tip: Electrolytic capacitors are polarised: connect the striped (negative) lead to the lower voltage side, as reversing it can make the capacitor fail. Keep a safety margin by using it up to about 70 V to 80 V, and discharge it through a resistor before handling, because at high voltage it can give an unpleasant shock.
