Electrolytic Capacitor(100V) 220uF (1pcs)

The Electrolytic Capacitor(100V) 220uF is a single aluminium electrolytic capacitor with a capacitance of 220 µF and a high maximum working voltage of 100 V. It suits bulk filtering and decoupling in higher-voltage DC circuits such as 48 V systems, motor controllers and audio amplifier power rails, where a 50 V or 63 V capacitor would not leave enough safety margin.

Electrolytic Capacitor(100V) 220uF Specifications

• Capacitance: 220 µF
• Rated voltage: 100 V DC
• Type: aluminium electrolytic, polarised
• Terminals: two leads, the stripe on the body marks the negative lead
• Stored energy: about 1.1 J when charged to 100 V (E = ½CV²)
• Pack size: 1 piece

Electrolytic Capacitor(100V) 220uF Applications

• Bulk capacitance on 24 V, 36 V and 48 V supply rails
• Input capacitors for DC-DC converters with a high input voltage
• Motor controllers and drivers running from higher-voltage batteries
• Power supply rails of audio amplifiers
• Repairing power supplies, inverters and control boards

What's in the Box

• 1 × 220 µF 100 V electrolytic capacitor

Tip: Electrolytic capacitors are polarised: connect the striped (negative) lead to the lower-voltage side, as reversing it can make the capacitor fail. Use it up to about 70–80 V to keep a safety margin, and discharge it through a resistor before handling, because a charged 220 µF capacitor at this voltage can give a painful shock.
