Electrolytic Capacitor (25V) 22uF (5pcs)

The Electrolytic Capacitor (25V) 22uF is a polarised electrolytic capacitor with a capacitance of 22 µF and a 25 V rating, sold in a pack of 5. Electrolytic capacitors give a lot of capacitance in a small size, so this value is widely used to smooth supply rails, decouple modules and pass audio signals between amplifier stages.

Electrolytic Capacitor (25V) 22uF Specifications

• Capacitance: 22 µF
• Rated voltage: 25 V DC
• Type: electrolytic, polarised
• Polarity marking: a stripe on the body marks the negative (−) lead
• Pack size: 5 pieces

Electrolytic Capacitor (25V) 22uF Applications

• Smoothing and filtering DC power supply rails
• Decoupling on modules, motor drivers and voltage regulators
• Coupling audio signals between amplifier stages
• RC timing circuits such as 555 timers
• Repair of power supplies and electronic boards

What's in the Box

• 5 × 22 µF 25 V electrolytic capacitors

Tip: Observe polarity: the stripe marks the negative lead, which is normally the shorter one. Use it in circuits up to about 20 V to leave a safety margin below the 25 V rating, and never connect it the wrong way round or to AC mains.
