Electrolytic Capacitor (50V) 470uF

Part no. 10312643

$0.35
In stock
  • Pick up in Msaitbeh, Beirut
  • Delivery across Lebanon
  • Bulk and education pricing on request
Description

The Electrolytic Capacitor (50V) 470uF is a polarised electrolytic capacitor with a capacitance of 470 µF and a 50 V rating. This large value stores enough charge to smooth the output of rectifiers and to steady supply lines that feed motors, servos and amplifiers, while the 50 V rating gives plenty of margin on 12 V and 24 V supplies.

Electrolytic Capacitor (50V) 470uF Specifications

  • Capacitance: 470 µF
  • Voltage rating: 50 V DC maximum
  • Type: electrolytic, polarised
  • Leads: two, the negative lead marked by a stripe on the sleeve
  • Quantity: 1 piece

Electrolytic Capacitor (50V) 470uF Applications

  • Smoothing capacitor after a bridge rectifier in DC power supplies
  • Bulk decoupling on motor driver and servo supply lines
  • Reservoir capacitor for audio amplifiers
  • Stabilising the input and output of voltage regulators
  • Repair of power boards and adapters

What's in the Box

  • 1 × 470 µF 50 V electrolytic capacitor

Tip: Connect the longer lead (+) to the positive side and the striped lead (−) to ground; reversing it or exceeding 50 V can make the capacitor fail. A capacitor this size can stay charged after power is removed, so discharge it through a resistor before touching the leads in high-voltage circuits.
