Electrolytic Capacitor(63V) 1000uF

The Electrolytic Capacitor(63V) 1000uF is a single aluminium electrolytic capacitor with a capacitance of 1000 µF and a maximum working voltage of 63 V. The large capacitance and high voltage rating make it suitable for smoothing rectified DC, holding energy for current peaks from motors and amplifiers, and decoupling supply rails in 24 V, 36 V and 48 V projects.

Electrolytic Capacitor(63V) 1000uF Specifications

• Capacitance: 1000 µF
• Rated voltage: 63 V DC
• Type: aluminium electrolytic, polarised
• Mounting: through-hole, two leads
• Polarity marking: the stripe on the body marks the negative lead
• Pack size: 1 piece

Electrolytic Capacitor(63V) 1000uF Applications

• Filtering rectified DC in linear power supplies
• Bulk capacitance at the input or output of voltage regulators
• Supply decoupling for motor drivers, audio amplifiers and LED strips
• Energy reserve for short current peaks
• Repairing power boards in amplifiers, inverters and appliances

What's in the Box

• 1 × 1000 µF 63 V electrolytic capacitor

Tip: Electrolytic capacitors are polarised: connect the striped (negative) lead to the lower voltage side, as reversing it can make the capacitor fail. Leave a safety margin by using it in circuits up to about 50 V, and discharge it through a resistor before handling, since at 63 V it stores about 2 J.
