Hakko FR-301 De-soldering gun

The Hakko FR-301 De-soldering gun is a portable desoldering tool from Hakko with the heater and vacuum pump built into one pistol-grip unit. Heat the joint with the hollow nozzle, pull the trigger and the molten solder is sucked into the tool, leaving the component lead and the plated hole free. It is made for technicians, repair shops and labs that remove through-hole components regularly and want a cleaner, faster result than a hand solder pump or desoldering wick.

Hakko FR-301 De-soldering gun Specifications

• Brand and model: Hakko FR-301
• Type: portable desoldering gun with built-in vacuum pump
• Operation: trigger-activated suction
• Design: self-contained, no separate desoldering station or air compressor needed
• Temperature range: 350–500 °C
• Nozzles: interchangeable, chosen to suit the lead and pad size
• Solder collection: inside the tool, emptied during routine cleaning

Hakko FR-301 De-soldering gun Applications

• Removing through-hole ICs, connectors and transformers from PCBs
• Repair and rework of electronic boards and power supplies
• Recovering components from old boards for reuse
• Clearing solder from plated through-holes before fitting a new part
• Electronics repair shops, service centres and university labs

What's in the Box

• 1 × Hakko FR-301 desoldering gun

Tip: Choose a nozzle slightly larger than the component lead and hold it on the joint until all the solder has melted, moving the lead gently in a small circle, then pull the trigger. Empty the solder collection chamber and clean or replace the filter regularly so the suction stays strong.
