Nano 33 BLE

The Arduino Nano 33 BLE is a compact development board built around the Nordic nRF52840, a 64 MHz Arm Cortex-M4F processor with Bluetooth Low Energy. It has a 9-axis IMU on board for motion sensing, keeps the classic Nano size, and is a popular board for wearables, Bluetooth gadgets and TinyML machine-learning projects.

Nano 33 BLE Specifications

• Microcontroller: Nordic nRF52840, Arm Cortex-M4F at 64 MHz
• Memory: 1 MB flash, 256 KB SRAM
• Wireless: Bluetooth Low Energy (Bluetooth 5)
• Sensors: 9-axis IMU (accelerometer, gyroscope, magnetometer)
• Operating voltage: 3.3 V
• Input voltage (VIN): up to 21 V
• I/O: 14 digital pins, 8 analog inputs, PWM on digital pins
• USB: micro-USB
• Size: 45 × 18 mm

Nano 33 BLE Applications

• Bluetooth LE sensors, remotes and phone-connected gadgets
• Gesture, motion and orientation sensing with the IMU
• TinyML and TensorFlow Lite Micro projects
• Wearables and battery-powered devices
• Robotics and IoT prototypes

What's in the Box

• 1 × Nano 33 BLE board

Tip: The Nano 33 BLE runs at 3.3 V and its pins are not 5 V tolerant, so use level shifting with 5 V modules. Install the Arduino Mbed OS Nano Boards package in the Arduino IDE board manager to program it.
