Rectifier Bridge KBPC310 3A 1KV

The Rectifier Bridge KBPC310 3A 1KV is a single-phase full-wave bridge rectifier rated for 3 A average output current and 1000 V (1 kV) peak reverse voltage. It packs four diodes into one part with four terminals, turning AC from a transformer into DC with a single component. The high voltage rating gives plenty of margin in power supplies, chargers and repair work.

Rectifier Bridge KBPC310 3A 1KV Specifications

• Type: single-phase full-wave bridge (4 diodes)
• Average output current: 3 A
• Peak repetitive reverse voltage: 1000 V
• Maximum RMS input voltage: 700 V
• Terminals: 4 (two ~ AC inputs, + and − outputs), marked on the body

Rectifier Bridge KBPC310 3A 1KV Applications

• DC power supplies with a step-down transformer
• Battery chargers and DC motor supplies
• Supplies for LED drivers, relays and solenoids
• Polarity protection on DC inputs
• Repair of power boards, adapters and appliances

What's in the Box

• 1 × KBPC310 bridge rectifier

Tip: Connect the two ~ terminals to the AC source, take DC from + and −, and add a smoothing capacitor. The output peaks at about 1.41 × the AC RMS voltage minus about 2 V, so 24 V AC gives roughly 32 V DC. Allow for cooling when running near 3 A.
