Rectifier Bridge RB152 2A 100V

The Rectifier Bridge RB152 is a single-phase full-wave bridge rectifier rated at 100 V peak reverse voltage. It contains four diodes in one compact round package with four leads, and converts AC from a low-voltage transformer into pulsating DC that a capacitor and regulator can then smooth. The RB152 belongs to the RB15x series, which is rated for 1.5 A average output current.

Rectifier Bridge RB152 Specifications

• Type: single-phase full-wave bridge rectifier (4 diodes)
• Maximum repetitive reverse voltage: 100 V
• Maximum RMS input voltage: 70 V
• Average forward current: 1.5 A
• Package: RB-15, round, 4 leads, through-hole
• Terminals: two AC (~) inputs plus + and − outputs, marked on the body

Rectifier Bridge RB152 Applications

• AC to DC power supplies with a 6 V to 24 V transformer
• Battery chargers and small adapters
• Rectifying AC for relays, solenoids and LED drivers
• Polarity protection so a DC input works either way round
• Repairs of power boards and small appliances

What's in the Box

• 1 × RB152 bridge rectifier

Tip: Two diodes conduct at any time, so the DC output is about 2 V lower than the AC peak voltage (peak = RMS × 1.41). Add a smoothing capacitor after the bridge, keep the load below 1.5 A, and choose a higher-current bridge if your circuit needs a full 2 A.
