Rectifier Bridge RB154 1.5A 400V

The Rectifier Bridge RB154 is a single-phase full-wave bridge rectifier rated at 1.5 A and 400 V. It contains four diodes in one compact round package with four leads, and converts AC from a transformer into pulsating DC that a capacitor and regulator can then smooth. It is a simple, space-saving part for small power supplies, chargers and repair work.

Rectifier Bridge RB154 Specifications

• Type: single-phase full-wave bridge rectifier (4 diodes)
• Maximum repetitive reverse voltage: 400 V
• Average forward current: 1.5 A
• Peak forward surge current: 50 A (8.3 ms half sine wave)
• Forward voltage drop: 1.0 V per diode at 1.0 A
• Package: RB-15, round, 4 leads, through-hole
• Terminals: two AC (~) inputs plus + and − outputs, marked on the body

Rectifier Bridge RB154 Applications

• AC to DC power supplies with a step-down transformer
• Battery chargers and small adapters
• Rectifying AC for relays, solenoids and LED drivers
• Polarity protection so a DC input works either way round
• Repairs of power boards and appliances

What's in the Box

• 1 × RB154 bridge rectifier

Tip: Two diodes conduct at any time, so the DC output is about 2 V lower than the AC peak voltage (peak = RMS × 1.41). Add a smoothing capacitor after the bridge and keep the load current below 1.5 A.
