Rectifier Bridge W04M 400V 1.5A

The Rectifier Bridge W04M 400V 1.5A is a single-phase full-wave bridge rectifier rated at 1.5 A and 400 V in a small round WOM package with four wire leads. It converts the AC from a transformer into DC in a single part, and its 400 V rating gives plenty of margin for transformer secondaries and 110–120 V AC lines, which makes it a popular choice for linear power supplies, chargers and repairs.

Rectifier Bridge W04M 400V 1.5A Specifications

• Type: single-phase full-wave bridge rectifier (4 diodes)
• Maximum repetitive reverse voltage: 400 V
• Maximum RMS input voltage: 280 V
• Average forward current: 1.5 A
• Peak surge current: 50 A (8.3 ms half sine wave)
• Package: WOM round case with 4 wire leads (two ~, + and −)

Rectifier Bridge W04M 400V 1.5A Applications

• Linear power supplies with step-down transformers
• AC to DC conversion for relays, solenoids and controllers
• Battery chargers and adapters
• Polarity protection on DC inputs
• Replacing bridge rectifiers in the same WOM package

What's in the Box

• 1 × W04M bridge rectifier, 400 V 1.5 A

Tip: For 230 V mains, which peaks at about 325 V, a W06M or higher-voltage bridge gives a safer margin against spikes. Connect the two ~ leads to the AC source, take DC from + and −, and keep the load below 1.5 A.
