Relay (9V) Songle SMI-09VDC-SL-C

Part no. 10190081

$0.50
In stock
  • Pick up in Msaitbeh, Beirut
  • Delivery across Lebanon
  • Bulk and education pricing on request
Description

The Relay (9V) Songle SMI-09VDC-SL-C is a sealed electromagnetic relay from the Songle SMI series with a 9 V DC coil and one set of changeover (SPDT) contacts. A small current through the coil switches a separate load circuit rated up to 10 A at 250 VAC, so it can control lamps, pumps, fans and appliances from a 9 V control circuit, or from a microcontroller through a transistor driver.

Relay (9V) Songle SMI-09VDC-SL-C Specifications

  • Coil voltage: 9 V DC
  • Contact form: 1 Form C (SPDT): COM, NO and NC
  • Contact rating: 10 A at 250 VAC
  • Max switching power: 2500 VA
  • Construction: sealed type
  • Mounting: PCB, through-hole pins

Relay (9V) Songle SMI-09VDC-SL-C Applications

  • Switching lamps, pumps and fans from Arduino or ESP32 through a transistor
  • 9 V control circuits and battery-powered controllers
  • Home automation and custom relay boards
  • Changeover circuits such as backup power or motor direction
  • Replacement relay in appliance control boards that use this model

What's in the Box

  • 1 × Songle SMI-09VDC-SL-C relay

Tip: A microcontroller pin cannot drive the coil directly: use an NPN transistor such as the BC547 or 2N2222, and fit a 1N4007 diode across the coil (band towards +9 V) to absorb the spike when it switches off. The SMI footprint differs from the common cube-shaped SRD relay, so check the datasheet pin layout before designing a PCB, and take care when switching mains voltage.
