Transformer AC 220V 2x6V 1VA

The Transformer AC 220V 2x6V 1VA is a small mains transformer that steps 220 V AC down to two 6 V AC outputs, with a total power rating of 1 VA. It provides isolated low-voltage AC for small linear power supplies, op-amp circuits that need a split supply, and mains-isolated sensing such as zero-cross detection.

Transformer AC 220V 2x6V 1VA Specifications

• Primary: 220 V AC
• Secondary: 2 × 6 V AC
• Power rating: 1 VA total
• Secondary current: about 83 mA when both 6 V halves are used together as 12 V (1 VA ÷ 12 V)
• Output: AC; needs a rectifier, filter capacitor and regulator for DC
• Isolation: secondary isolated from the mains

Transformer AC 220V 2x6V 1VA Applications

• Small linear power supplies for low-current circuits
• Split ± supplies for op-amp and audio preamp projects
• Zero-cross detection and mains-synchronised timing
• Standby and indicator power in appliances
• Teaching transformers, rectifiers and AC in electronics labs

What's in the Box

• 1 × Transformer AC 220 V to 2 × 6 V, 1 VA

Tip: The primary connects to 220 V mains, so insulate its terminals, fit a fuse and mount the transformer in a closed enclosure. Small transformers give a noticeably higher voltage with no load, so measure the output under real load before choosing your regulator.
