Varistor 250pF 100V 101K 5pcs

The Varistor 250pF 100V 101K is a disc-type metal oxide varistor (MOV) with a varistor voltage of 100 V, sold in a pack of 5. A varistor is a voltage-dependent resistor: it barely conducts at normal working voltage, then conducts heavily when a spike or surge pushes the voltage above its rating, clamping the spike and protecting the circuit behind it.

Varistor 250pF 100V 101K Specifications

• Type: metal oxide varistor (MOV), disc, 2 radial leads, through-hole
• Varistor voltage: 100 V (code 101 = 10 × 10¹), measured at 1 mA DC
• Tolerance: ±10% (letter K)
• Capacitance: 250 pF (typical, as listed)
• Typical maximum continuous voltage for the 101K code: 60 V AC / 85 V DC
• Polarity: none, works in both directions
• Pack size: 5 pieces

Varistor 250pF 100V 101K Applications

• Surge protection in 24 V and 48 V DC systems such as solar, battery and telecom supplies
• Protecting low-voltage AC circuits up to 60 V, for example 24 V AC transformer outputs
• Suppressing spikes from DC motors, relays and solenoids
• Protecting the power inputs of controllers, modules and LED drivers

What's in the Box

• 5 × 100 V (101K) varistors

Tip: Connect the varistor in parallel with the supply you want to protect, after a fuse, so that if it ever fails short the fuse opens. Do not use the 101K on mains voltage; it is meant for low-voltage circuits only.
