XF-25 Ultra Minibreadboard White

The XF-25 Ultra Minibreadboard White is a tiny white solderless breadboard with 25 tie points in a 5 × 5 grid, roughly 15 × 20 mm in size. It is made for very small circuits, such as one sensor, a couple of LEDs or a breakout board, and lets you plug in, change and reuse parts without soldering. Its small footprint fits inside robot chassis, model kits and project boxes.

XF-25 Ultra Minibreadboard White Specifications

• Model: XF-25 ultra mini breadboard
• Colour: white
• Tie points: 25, in a 5 × 5 grid
• Size: approx. 15 × 20 mm
• Hole pitch: 2.54 mm (0.1 in), standard breadboard pitch
• Wire size: accepts 20–29 AWG solid wire and component leads
• Mounting: two small holes on the back for fixing it to an XF-25 base plate (not included)

XF-25 Ultra Minibreadboard White Applications

• Tiny sensor or LED circuits inside robots, models and toys
• A shared power and ground point for jumper wires
• Quick tests of a single component or breakout board
• Colour-coded circuit sections using boards of different colours
• Classroom and STEM projects

What's in the Box

• 1 × XF-25 ultra mini breadboard, white

Tip: Use the continuity mode of a multimeter to see which holes are linked before placing parts. Combining several XF-25 boards in different colours is an easy way to keep power, ground and signal sections apart.
