10 Pin Female 11mm tall stackable Header Connector (5/Pack)

The 10 Pin Female 11mm tall stackable Header Connector pack contains 5 single-row female headers with 10 contacts each and long straight pins that pass through the board. Solder one to a shield or perfboard and you get a female socket on top and male pins underneath, so your board can plug into an Arduino and still let you stack another board or plug jumper wires in above.

10 Pin Female 11mm tall stackable Header Specifications

• Contacts: 10, single row
• Style: female socket on top, long straight pins below (stackable)
• Height: 11 mm tall (as listed)
• Pitch: 2.54 mm (0.1 in)
• Mounting: through-hole, solder
• Pack size: 5 pieces

10 Pin Female 11mm tall stackable Header Applications

• Arduino Uno R3 shields: the 10-pin size matches the header with D8–D13, GND, AREF, SDA and SCL
• Stackable add-on boards and custom shields
• Removable sockets for modules on perfboard
• Raising a board to clear tall components

What's in the Box

• 5 × 10-pin stackable female headers

Tip: To keep the headers straight while soldering, plug them into the board they will stack onto, place your shield on top and solder from above. Do not trim the long pins, as they plug into the board below. A full Uno R3 shield uses one 10-pin header, two 8-pin headers and one 6-pin header.
