170pts Mini Breadboard SYB-170 (Black)

The 170pts Mini Breadboard SYB-170 is a small black solderless breadboard with 170 tie points for building and testing compact circuits without soldering. It is big enough for a few components, a small IC or a sensor, and small enough to fit inside a robot, an enclosure or next to an Arduino. Components and jumper wires push in and pull out, so the board can be reused again and again.

170pts Mini Breadboard SYB-170 Specifications

• Model: SYB-170
• Tie points: 170
• Layout: 17 columns, each with two groups of 5 connected holes separated by a centre channel
• Power rails: none
• Hole pitch: 2.54 mm (0.1 in)
• Colour: black

170pts Mini Breadboard SYB-170 Applications

• Small LED, button and sensor test circuits
• Mounting circuits on robot chassis or inside project boxes
• Add-on circuits next to an Arduino or ESP32
• Testing DIP ICs such as the NE555 or a small op-amp
• Classroom kits where each student gets a small board

What's in the Box

• 1 × SYB-170 mini breadboard, black

Tip: This board has no power rails, so set aside one column for 5 V and one for GND and link them with jumper wires. Avoid forcing thick leads into the holes, as this can loosen the spring contacts inside.
