170pts Mini Breadboard SYB-170 (Red)

The 170pts Mini Breadboard SYB-170 is a small red solderless breadboard with 170 tie points for building and testing compact circuits without soldering. It has room for a few components, a small IC or a sensor, and it is small enough to fit on a robot, inside an enclosure or next to an Arduino. Components and jumper wires push in and pull out, so the board can be reused many times, and the red colour makes it easy to tell circuits apart.

170pts Mini Breadboard SYB-170 Specifications

• Model: SYB-170
• Tie points: 170
• Layout: 17 columns, each with two groups of 5 connected holes separated by a centre channel
• Power rails: none
• Hole pitch: 2.54 mm (0.1 in)
• Colour: red

170pts Mini Breadboard SYB-170 Applications

• Small LED, button and sensor test circuits
• Mounting circuits on robot chassis or inside project boxes
• Add-on circuits next to an Arduino or ESP32
• Testing DIP ICs such as the NE555 or a small op-amp
• Classroom kits where each student or group gets its own board

What's in the Box

• 1 × SYB-170 mini breadboard, red

Tip: This board has no power rails, so set aside one column for 5 V and one for GND and link them with jumper wires. Do not force thick leads into the holes, as this can loosen the spring contacts inside.
