2 x AA Battery Holder Box (Back-to- Back)

The 2 x AA Battery Holder Box holds two AA batteries back to back, one on each side of the holder, which makes it shorter and more compact than a side-by-side holder. The two cells are connected in series to give about 3 V from alkaline batteries, delivered through wire leads ready to connect to your circuit. It is a simple, low-cost way to power small motors, LEDs, buzzers and other low-voltage projects.

2 x AA Battery Holder Box Specifications

• Battery type: AA (batteries not included)
• Capacity: 2 cells
• Layout: back to back, one cell on each side
• Wiring: cells in series
• Output voltage: about 3 V with alkaline cells (2 × 1.5 V), about 2.4 V with NiMH rechargeables
• Connection: two wire leads

2 x AA Battery Holder Box Applications

• Small DC motors and toy projects
• LED, buzzer and simple light circuits
• 3 V sensors and modules
• School science and STEM projects
• Portable gadgets and remote controls

What's in the Box

• 1 × 2 x AA battery holder with leads

Tip: Follow the + and − marks inside the holder when fitting the batteries. 3 V is too low for the barrel jack or VIN pin of an Arduino Uno, so use this holder for 3 V loads, or add a boost converter if your project needs 5 V.
